Pure 200

200mm/8" Triple Glazed | Rw 64 dB

Designed for recording studios, broadcast suites, and confidential workspaces, Pure 200 delivers industry-leading acoustic performance with ratings up to Rw 64 dB.

ACOUSTICS
up to Rw 64 dB

FIRE RATING
Non fire rated

MAX HEIGHT
up to 3000mm

Downloads Specifications Enquire Now

Technical Information.

	ACOUSTICS	up to Rw 64 dB
	AVAILABLE FINISHES	PPC powder coated, polished, anodised
	CURVE RADIUS	N/A
	DEFLECTION	No deflection
	DOORS	N/A
	FIRE RATING	Non fire rated
	FRAME MATERIAL	Aluminium
	FRAMEWORK	200mm(w) x 27mm(h)
	GLASS JOINT TYPE	Clear butt jointed
	GLASS THICKNESS	10mm to 12.8mm
	MAX HEIGHT	up to 3000mm

Downloads

Pure 200 (TG) Frameless Glass Partition System - Planet Designer's Guide

Unlock Download

Pure 200 (TG) Frameless Glazed Partition System - Data Sheet

Unlock Download

Complete Range.

Pure 20

20mm/1" Single Glazed | Up to 40 dB

ACOUSTICS	up to Rw 40 dB
FIRE RATING	Non fire rated
MAX HEIGHT	up to 3000mm

Our 20mm wide single glazed partition offers a maximum glazed area, coupled with minimalistic perimeter profiles, for a truly frameless look.

Learn More

Pure 20 XL

20mm/1" Single Glazed Extended Height

ACOUSTICS	up to Rw 40 dB
FIRE RATING	Non fire rated
MAX HEIGHT	up to 4600mm

Pure 20 XL is a sleek, minimalistic single-glazed partition system with an slim 27mm profile designed for extended height applications.

Learn More

Pure 54

54mm/2" Single & Double Glazed | Up to 46 dB

ACOUSTICS	up to Rw 46 dB (DG); 40 dB (SG)
FIRE RATING	Non fire rated
MAX HEIGHT	up to 3000mm

Our narrow 54mm wide glazed partition is available in both single and double glazed formats and provides outstanding style with enhanced performance.

Learn More

Pure 100

100mm/4" Single & Double Glazed | Up to 54 dB

ACOUSTICS	up to Rw 54 dB (DG); 40 dB (SG)
FIRE RATING	Non fire rated
MAX HEIGHT	up to 3000mm

Our 100mm wide glazed partitioning offers superior acoustic performance with a vast range of configuration options, to satisfy even the most demanding of interior design schemes.

Learn More

Current Product

Pure 200

200mm/8" Triple Glazed | Rw 64 dB

ACOUSTICS	up to Rw 64 dB
FIRE RATING	Non fire rated
MAX HEIGHT	up to 3000mm

Designed for recording studios, broadcast suites, and confidential workspaces, Pure 200 delivers industry-leading acoustic performance with ratings up to Rw 64 dB.

Learn More

Add to your NBS specification

All of Planet's products are available on the NBS Source platform.

Use the links below to add our range directly into your specification

All of Planet's products are available on the NBS Source platform.

Use the links below to add our range of Pure frameless glazed partitioning systems directly into your specification.
