Linear 25

British American Tobacco BAT Southampton Planet 2024 HR Overbury 63

Linear 25

25mm | Up to Rw 39 dB

View Details

Linear 30

+ -

Linear 30

30mm | Up to Rw 41 dB

View Details

Linear 50 / 50+

+ -

Linear 50 / 50+

50mm | Up to Rw 41 dB

View Details

Linear 59

+ -

Linear 59

59mm | Up to Rw 39 dB

View Details

Linear 64

+ -

Linear 64

64mm | Up to Rw 41 dB

View Details

Linear 30.

Fire Rating
Non Fire Rated

Acoustics
Up to Rw 39 dB

Maximum Height
up to 3650mm

Linear 30 is a 30 mm wide single glazed partition system that offers a very high (Rw 41 dB) acoustic performance compared to other single glazed systems. Ideal for offices and meeting rooms.

KEY FEATURES & OPTIONS.

1. Available with our 'Rio' feature banding.
2. Can incorporate many of our glass and timber door solutions, both in pivoting and sliding configurations.
3. Deflection heads available up to +/- 25 mm.
4. Environmental Product Declaration (EPD) available on request.

British American Tobacco BAT Southampton Planet 2024 HR Overbury 49

01.

British American Tobacco BAT Southampton Planet 2024 LR Overbury 35

British American Tobacco BAT Southampton Planet 2024 LR Overbury 37

British American Tobacco BAT Southampton Planet 2024 LR Overbury 34

HIGH-END COMMERCIAL SINGLE GLAZED PARTITIONS

The Linear family offers minimal, elegant single glazed systems that are versatile in both acoustic performance and design.

Capable of being installed with concealed deflection heads and with a number of base track height options available, Linear can be specified to match the designer's intent to align horizontal lines throughout a space.

Furthermore, though typically configured up to heights of 3000mm, extension up to 3650mm is possible though the use of transom bars.

Typically available in 25mm, 30mm and 50mm profiles, Linear can achieve up to 41dB acoustic performance and can be manufactured with a number of glazing options including toughened, laminate, or decorative glass. Framework can be produced in any colour through anodising or powder coating and samples provided.

59mm and 64mm profiles come exclusively with top-hung sliding door installations.

Our single glazed partitioning can incorporate many of our glass and timber door solutions, both in pivoting and sliding configurations.

ADD TO YOUR NBS SPECIFICATION

All of our products are available on the NBS Source platform.

Use the links below to add our range of Linear glazed partitioning systems directly into your specification.

Low Carbon Aluminium.

At Radii Planet Group, we are leading this transformation by transitioning to using Hydro Recycled Low Carbon 2.0 Aluminium for our Radii aluminium framed glass partitions.

Hydro Recycled Low Carbon 2.0 guarantees that for every kilogram of aluminium produced, only up to 2kg of CO2e is emitted—substantially lower than traditional aluminium production.

By utilising recycled content, we not only reduce emissions but also conserve valuable resources, demonstrating how circular economy practices can play a key role in mitigating climate change.
